FRAME
Spark Alloy SL 6011
Integrated Suspension Technology
Flex Pivot / Adjustable head angle
Syncros Cable Integration System
BB92 / UDH Interface / 12x148mm with 55mm ChainlineFORK
RockShox Judy Silver TK Solo Air
15x110mm QR axle / 42mm offset / Tapered Steerer
2-Modes / Reb. Adj. / Lockout / 130mm travelREAR SHOCK
X-Fusion NUDE 5 RLX Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout-Traction Control-Descend
Reb. Adj.
Travel 120-80-Lockout / T165X45mmREMOTE SYSTEM
SCOTT TwinLoc 2 Technology
Suspension & Dropper Remote
3 Suspension modes
REAR DERAILLEUR
Shimano XT RD-M8100 SGS
Shadow Plus / 12 SpeedSHIFTERS
Shimano Deore SL-M6100-R / Rapidfire PlusCRANKSET
Praxis Cadet M24
55mm CL / 32TBB-SET
Praxis M24 BB92 / shell 41x92mmCHAIN
KMC X12CASSETTE
Shimano Deore CS-M6100-12 / 10-51 TBRAKES
Shimano MT501 DiscROTOR
Shimano SM-RT54 CL / F&R 180mmHANDLEBAR
Syncros Fraser 2.0 DC Alloy 6061 D.B.
mini Rise / back sweep 8° / 760mm
Syncros Performance XC lock-on gripsH’STEM
Syncros DC 3.0
Syncros Cable Integration System
0° rise / 6061 Alloy / 31.8mm / 1 1/8″SEATPOST
Syncros Duncan Dropper Post 2.5
31.6mm / S & M size 125mm / L size 150mm / XL size 170mmSEAT
Syncros Tofino 2.5 RegularHEADSET
Syncros – Acros Angle adjust & Cable Routing HS System
+-0.6° head angle adjustment
ZS56/28.6 – ZS56/40 MTBHUB (FRONT)
Shimano HB-MT410-B CL / 15x110mmHUB (REAR)
Shimano FH-MT410-B CL / 12x148mm / Micro SplineSPOKES
Stainless Black 15G / 1.8mmRIMS
Syncros X-30SE / 32H / 30mmFRONT TIRE
Schwalbe Wicked Will / 29×2.4″
Performance / TLR / Foldable / AddixREAR TIRE
Schwalbe Wicked Will 29×2.4″
Performance / TLR / Foldable / AddixAPPROX WEIGHTS IN KG
14.95 (with tubes)APPROX WEIGHTS IN LBS
32.96 (with tubes)MAX. SYSTEM WEIGHT
128kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
